Profiler ZPM 2500 / TPM 2500
Machine for pleating and stiffening of duct work
This machine is used for pleating and stiffing of metal sheets used in duct work. The standard profile is the Z-profile and it is ideally suited duct stiffening, but optionally the machine can be equipped with T-profiling rolls as well.
![Sickenmaschine](../images/pleater.jpg)
Technical Data:
Material: |
galv. steel: 0.5 to 1.5mm
INOX / stainless steel: 0.4 to 1.0mm
Aluminum: 0.4 to 1.0mm
|
Max. sheet width: |
2500 mm
|
Z-Profil: |
160 mm x 7-12 mm |
T-Profil: |
50 mm x 1 mm |
Operating speed: |
15-20 m/min |
Working height: |
900 mm |
Weight: |
850 kg |
Power supply: |
3 x 400 V / 50 Hz, 2.2 kVA
|
![Profile](../images/profile.jpg) |
This machine can be equipped with either the standard Z-profiling rolls ZPM 2500, or optionally with T-profiling rolls TPM 2500. |
|
